QS SMART Outdoor Scoreboards

Use Cases: School and University Sports Grounds, Sports Stadiums and Arenas

Quickscore SMART scoreboards are controlled by Apps and are multi-sport/ multi-functional screens. The scoreboard currently is integrated with uses for Cricket (CricHQ or TCS, PlayCricket and QS Cricket), Rugby, Football, Field Hockey, Baseball and Athletics (and any sports requiring a leader board for individuals as well as cumulative stats).

For larger, custom sized scoreboards or perimeter advertising screens then please do get in touch for a quote.

QS 100

Technical Specifications

  • Resolution: 256 x 128px
  • Dimensions: 2560 x 1280 x 119 mm
  • Optimal Viewing Distance: 10-120 meters
  • Weight: 120 kg
  • Average Power Consumption: <500W
  • Pixel Pitch: 10mm
  • LED Type: DIP346 1R1G1B
  • LED Lifetime: 100000 hours
  • Viewing Angle ( H X V ): 120∘ x 55∘
  • Brightness: 7000 nits
  • Warranty: 1 Year
  • Certification: CE, WiFi, EMC, IP65/54
  • Wireless Security: WEP, WPA/WPA2 encryptions
  • Network Type: 4G: FDD-LTE, 3G: DC-HSPA+/HSPA+

QS 200

Technical Specifications

  • Resolution: 320 x 192px
  • Dimensions: 3200 x 1920 x 119 mm
  • Optimal Viewing Distance: 10-150 meters
  • Weight: 225 kg
  • Average Power Consumption: <1000W
  • Pixel Pitch: 10mm
  • LED Type: DIP346 1R1G1B
  • LED Lifetime: 100000 hours
  • Viewing Angle ( H X V ): 120∘ x 55∘
  • Brightness: 7000 nits
  • Warranty: 1 Year
  • Certification: CE, WiFi, EMC, IP65/54
  • Wireless Security: WEP, WPA/WPA2 encryptions
  • Network Type: 4G: FDD-LTE, 3G: DC-HSPA+/HSPA+

QS 200+

Technical Specifications

  • Resolution: 360 x 180 px
  • Dimensions: 3840 x 1920 x 96 mm
  • Optimal Viewing Distance: 10-160 meters
  • Weight: 228 kg
  • Average Power Consumption: <1083W
  • Pixel Pitch: 10.66mm
  • LED Type: DIP346 1R1G1B
  • LED Lifetime: 100000 hours
  • Viewing Angle ( H X V ): 120∘ x 60∘
  • Brightness: 6500 nits
  • Warranty: 1 Year
  • Certification: CE, Rohs,ETL, FCC, CCC, WiFi, EMC, IP65/54
  • Wireless Security: WEP, WPA/WPA2 encryptions
  • Network Type: 4G: FDD-LTE, 3G: DC-HSPA+/HSPA+

Features
